Processor :
One 2nd Gen AMD EPYC Processor with up to 64 cores
Operating System
Canonical Ubuntu Server LTS
Citrix Hypervisor
Microsoft Windows Server with Hyper-V
Red Hat Enterprise Linux
SUSE Linux Enterprise Server
VMware ESXi
Bezel :
Optional LCD bezel or security bezel
Memory
DIMM Speed : Up to 3200MT/s
Memory Type : RDIMM / LDIMM
Memory Module Slots : 16 DDR4 RDIMM/LRDIMM slots
Maximum RAM : RDIMM 1TB / LRDIMM 2TB
Rack Support
ReadyRails™ sliding rails with optional cable management arm for 4-post racks (optional adapter brackets required for threaded hole racks).
Storage
Front Bays
Up to 4 x 3.5" hot plug SAS/SATA (HDD)
Up to 10 x 2.5" hot plug SAS/SATA/NVMe
Up to 8 x 2.5" hot plug SAS/SATA
Ports
Network Options
2 x 1GbE
2 x 10GbE BT
2 x 10GbE SFP+
2 x 25GbE SFP28
Front Ports
1 x Dedicated iDRAC direct micro-USB
1 x USB 2.0
1 x Video
Rear Ports
2 x 1GbE
1 x Dedicated iDRAC network port
1 x Serial
2 x USB 3.0
1 x Video
Storage Controllers
Internal Controllers :PERC HBA330, H330, H730P, H740P
External Controllers (RAID) : H840, 12Gbps SAS HBA
Internal Boot
Boot Optimized Storage Subsystem (BOSS): HWRAID 2 x M.2 SATA SSDs
Internal Dual SD Module
Form Factor :
1U Rack Server
Power Supplies :
550W Platinum
Slots
PCIe : Up to 2: 1 x Gen3 slot (1 x16) ; 1 x Gen4 slot (1 x16)
